20XP – TRACK

The 20XP is an entry level whole tree track chipper and a great choice for those looking at a compact, yet rugged machine for lot and land clearing applications. Officially rated as a 22-inch capacity machine, this exceptionally versatile chipper actually features a large 26.25-inch by 24.5-inch throat opening to easily handle large whole trees. A Caterpillar 308 or 312B steel track undercarriage provides a stable travel platform.

Caterpillar engines are available with 275 or 321 horsepower and a standard wireless radio remote control with tether back-up will control all chipper functions.

With an open top infeed hopper, the 20XP can easily be fed with a loader and the optional 5 1/2′ infeed conveyor further assists with feeding material into the chipper drum. The standard 270 degree hydraulic swivel discharge allows for broadcasting chips or an optional forestry style discharge can be ordered for additional chip throwing velocity. A loader is also available as an option eliminating the need for an additional loader on site.

Specifications

Capacity 22"
Opening 26.25" x 24.50
Width 102 in
Height 128 in
Length 220 in
Weight 22,000 pounds (will vary with engine and options)
Fuel Tank 50 gallons
Hydraulic Tank 50 gallons

Benefits and Features
