20XP – TOWABLE

The 20XP is an entry level whole tree chipper and a great choice for those looking for a compact, yet rugged machine. Officially rated as a 20-inch capacity machine, this exceptionally versatile chipper actually features a large 26.25-inch by 24.5-inch throat opening to easily handle large whole trees. Bandit’s Slide Box Feed System has no problem pulling in and crushing the most stubborn forked limbs and dense hardwood.

Caterpillar, Cummins or John Deere engines are available ranging from 275 to 350 horsepower. A standard wireless radio remote control with tether back-up controls all chipper functions.

With an open top infeed hopper, the 20XP can easily be fed with a loader and the optional 5 1/2′ infeed conveyor further assists with feeding material into the chipper drum. The standard 270 degree hydraulic swivel discharge allows for broadcasting chips or an optional forestry style discharge can be ordered for additional chip throwing velocity. A loader is also available as an option eliminating the need for an additional loader on site.

capacity-standard

20 in

capacity-metric

50.80 cm

average_trailer_load_time_-standard

45-50 min

opening-standard

24.50 in x 26.25 in

opening-metric

66.67 cm x 62.23 cm

width-standard

102 in

width-metric

259.08 cm

height-standard

128 in

height-metric

325.12 cm

length-standard

220 in

length-metric

558.80 cm

weight-standard

20000 lbs

weight-metric

9071.85 kg

fuel_tank-standard

50 gl

fuel_tank-metric

189.27 l

hydraulic_tank-standard

50 gl

hydraulic_tank-metric

189.27 l
