Equipped with CAT C18 engine and CAT TA22H transmission, the 630hp exceeds that of Ag tractor manufacturers who try to modify their field tractors for pulling pans in construction.
| Engine HP at Rated RPM | 630 hp at 2,000 rpm |
| Engine Manufactor | Caterpillar |
| Engine Type | Cat ACERT C18 Tier 4 Final |
| Transmission | Cat TA22H 16 Speed Powershift |
| Quick Hitch Drawbar and Hitch Plate | Standard |
| Height | 152 in |
| Width (With Duals) | 189 in |
| Width (Without Duals) | 142 in |
| Ground Clearance | 19 in |
| Length | 308 in |
| Weight | 53,890 lbs |
| Degrees of Articulations | 29 |
| Degrees of Oscillation | 15 |
