280XP – TOWABLE

Bandit’s largest hand-fed disc-style chipper is designed for tree service professionals regularly involved in large tree takedowns. This 18-inch capacity chipper features a large 18.5-inch by 20-inch throat opening to easily accept multiple branches and whole trees. Using Bandit’s proven Slide Box Feed System, the Model 280XP has no problem pulling in big trees, crushing limby, forked branches, or processing multiple stems at once. A variety of engine options are available ranging from 165 to 300 horsepower.

capacity

18 in

capacity_-_metric

45.72 cm

opening-standard

20.50 in x 18 in

opening-metric

52.07 cm x 52.07 cm

width-standard

88 in

width-metric

223.52 cm

height-standard

114 in

height-metric

289.56 cm

length-standard

224 in (Open), 194 in (Closed)

length-metric

568.96 cm (Open), 492.76 cm (Closed)

weight-standard

14,000

weight-metric

6350 kg

feed-rate

100 ft/min

feed-rate-metric

30.48 m/min

fuel-tank-standard

60 gl

fuel-tank-metric

227 l

hydrolic-tank-standard

32 gl

hydrolic-tank-metric

121.13 l

  • 55" diameter x 2" thick chipper disc
  • 20" wide diameter x 10 5/8" diameter feed wheels
  • Hand crank swivel discharge
  • Driven by (2) 63.9 CID hydraulic motors / chain
  • Optional 32" wide feed wheels
  • Standard hydraulic lift cylinder
  • Optional hydraulic swivel discharge
