TH1055 Telehandler

The Next Generation Cat® TH1055 Telehandler is focused on safety and ease of operation, with extended service intervals so it is ready to work when you are.

More than a machine – Cat Telehandlers are an extension of you.

Buy Used

Operating Specifications

Rated Load Capacity 10000lb
Maximum Lift Height 54.6ft
Maximum Forward Reach 41ft
Frame Leveling 10 degrees
Drawbar Pull - Loaded 29157lbf
Capacity at Maximum Lift Height (Stabilizers Down) 5000lb
Capacity at Maximum Forward Reach (Stabilizers Down) 3000lb
Operating Weight 29838lb
Maximum Ground Bearing Pressure (Solid Tires) 225psi
Maximum Ground Bearing Pressure (Pneumatic Tires) 170psi
Travel Speed – Forward 18mile/h
Travel Speed – Reverse 13mile/h
Turning Radius over Tires (2-wheel steer) 259in
Turning Radius over Tires (4-wheel steer) 157in
Note Operating Specifications, and Dimensions are based on 55 kW (74 hp) engine, pneumatic tires, open canopy, 1829 mm (72 in) standard carriage, 1829 mm (72 in) forks, full fluids, and 80 kg (176 lb) operator.
Note (1) Travel Speeds and Drawbar Pull are based on the 86 kW (115 hp) engine.

Engine - Standard

Model Cat C3.6
Emissions Meets U.S. EPA Tier 4 Final/EU Stage V emissions standards.
Gross Power ISO 14396:2002
Gross Power 74hp
Displacement 220in³

Engine - Option 1

Model* Cat C3.6
Emissions Meets U.S. EPA Tier 4 Final/EU Stage V emissions standards.
Gross Power ISO 14396:2002
Gross Power 115hp
Displacement 220in³

Weight Additions (add to base configured weight)

Engine* 194lb
Enclosed Cab (with Air Conditioning) 364lb
Solid Tires 1905lb
Fenders (set of 4) 119lb
Note * 86 kW (115 hp) Engine

Hydraulic System

Auxiliary Hydraulic Flow 14.5gpm
Auxiliary Hydraulic Pressure 4061psi
Maximum Pump Flow 37gpm
System Operating Pressure 4061psi

Service Refill Capacities

Fuel Tank 39gal (US)
Diesel Exhaust Fluid (DEF) Tank 5gal (US)
Hydraulic Tank 24gal (US)
Hydraulic System 44gal (US)
Engine Crankcase 2.4gal (US)
Transmission 5.3gal (US)
Transfer Case 0.7gal (US)
Note Diesel Exhaust Fluid (DEF) is only applicable for 86 kW (115 hp) engine option.

Transmission Speeds

Forward 4 Gears
Reverse 3 Gears

Tires

Option (1) 17.5-25 Galaxy Giraffe XLW L-2 (Air)
Option (2) 14-24 Camso TLH 792S (Solid)
Option (3) 14-24 Maxam MS709 (Solid)

Braking System

Service Brakes Inboard wet disc brakes on front and rear axles
Parking Brakes Wet disc, spring applied hydraulic release (front axle)

Boom Performance

Boom Down 14.9 sec
Boom Up 14.5 sec
Tele In 20.5 sec
Tele Out 19.4 sec

Dimensions (Approximate)

Height - Machine Rear 106in
Overall Length to Front of Carriage 252in
Overall Width - Stabilizers Down 146in
Overall Width - Standard Tires 97in
Wheel Base 131in
Ground Clearance 18in

Sound

Exterior Sound 82 dB(A)
Operator Sound 79dB(A)

Air Conditioning System

Air Conditioning The air conditioning system on this machine contains 0.68 kg (1.5 lb) of refrigerant. The refrigerant is either R134a or R1234yf. If equipped with R134a (Global Warming Potential = 1430), the refrigerant in the system has a CO2 equivalent of 0.972 metric

Sustainability

Recyclability 98%

Standard Equipment

  • Engine
    • 55 kW (74 hp)
  • Cold Weather
    • Battery disconnect with lockout feature
  • Operator Station
    • Canopy
  • Operating Enhancers
    • Operator Presence Seat Switch
    • Camera, rearview
    • Load Stability Indicator (LSI)
  • Operator Seat
    • Seat – Mechanical Suspension
  • Seat Belt
    • Seat belt – 51 mm (2 in)
  • Operator Station Accessories
    • USB dual charging port (USB-A and USB-C)
    • Security, 4 digit operator code enabled
    • Wiper, front (enclosed cab only)
  • Fenders
    • Cab fender (Left Hand front)
  • Other Options
    • Frame cover
    • Retrieval hitch
  • Lights
    • LED work lights – cab, boom
  • Telematics
    • PLE643 – Product Link™ Elite
  • Attachment Coupler
    • TH Coupler (Manual)
  • Auxiliary Hydraulic Connections
    • Capped auxiliary hydraulic lines
  • Stabilizers
    • Front Stabilizers

Optional Equipment

  • Engine
    • 86 kW (115 hp)
  • Cold Weather
    • Cold Weather Package
    • Dual Battery, heavy duty
    • Engine Block Heater
    • Ether Starting Aid
  • Operator Station
    • Enclosed Cab, heat
    • Enclosed Cab, heat, air conditioner
  • Operator Seat
    • Seat – Mechanical Suspension Plus
  • Seat Belt
    • Seat belt – 75 mm (3 in)
    • Seat belt with Indicator – 75 mm (3 in)
  • Operator Station Accessories
    • Security, Bluetooth® key
    • Hydraulic lockout switch
    • Wiper, rear (enclosed cab only)
    • Wiper, roof (enclosed cab only)
    • Sunshade (top window)
    • Padlocks (set of 4)
  • Fenders
    • Fenders (4 Wheels)
  • Guarding
    • Window guard, front
    • Window guard, top
  • Other Options
    • Boom prop
  • Lights
    • Beacon
    • Roading lights
  • Tires
    • Galaxy – pneumatic directional
    • Camso – solid directional
    • Maxam – solid non-directional
  • Attachment Coupler
    • IT Coupler (Manual)
    • IT Coupler (Hydraulic)
  • Auxiliary Hydraulic Connections
    • Twist to connect hydraulic quick disconnects
  • Carriage
    • Standard – 1270 mm (50 in)
    • Standard – 1829 mm (72 in)
    • Side Tilt/Rotating – 1270 mm (50 in)
    • Side Tilt/Rotating – 1829 mm (72 in)
    • Hydraulic Fork Positioner – 1829 mm (72 in)
  • Forks
    • Pallet Forks – 1220 mm (48 in)
    • Pallet Forks – 1525 mm (60 in)
    • Pallet Forks – 1829 mm (72 in)
  • Other Work Tool Attachments
    • General Purpose Bucket
    • Truss Boom – 3.7 m (12 ft)
