M318F Wheeled Excavator

Working hard has never been easier with Cat® F Series Wheeled Excavators. Enjoy the versatility offered by integrated solutions and technologies that do repetitive tasks for you. These machines are designed to help you take on the wide variety of challenges you face every day, and at a lower cost.

Engine

Engine Model Cat C7.1
Net Power 169HP
Bore 4.1in
Stroke 5.3in
Displacement 427.8in³
Maximum Torque - 1,400 rpm 578ft-lb
Note *Metric values.
Engine Power - Maximum Gross - ISO 14396 129.4 kW (174 hp [176 hp]*)
Engine Power - Maximum Net - ISO 9249/SAE J1349 126 kW (169 hp [171 hp]*)
Ratings 1750r/min
Number of Cylinders - In Line 6
Emissions Meets Tier 4 Final/Stage IV emission standards.

Drive

Maximum Travel Speed 22mile/h

Swing Mechanism

Swing Speed 10r/min
Maximum Swing Torque 30977ft-lb

Transmission

Drawbar Pull 23155lbf
Maximum Forward/Reverse - 2nd Gear 22mile/h
Maximum Gradeability (17 500 kg/38,580 lb) 75%

Undercarriage

Ground Clearance 14.6in
Maximum Towable Trailer Mass* 17637lb
Note *For Optional Trailer Package – Not available in Australia/New Zealand.

Working Ranges

VA Boom - 2400 mm (7'10") Stick Length: Digging Height 33.75ft
One-Piece Boom - 2400 mm (7'10") Stick Length: Digging Depth 18.67ft
Note Range values are calculated with GD bucket 1200 mm (48 in), 0.91 m3 (1.19 yd3) with tips K080 and quick coupler with a tip radius of 1574 mm (5'2").
One-Piece Boom - 2600 mm (8'6") Stick Length: Digging Height 30.33ft
One-Piece Boom - 2600 mm (8'6") Stick Length: Reach at Ground Level 30.17ft
One-Piece Boom - 2400 mm (7'10") Stick Length: Dump Height 20.08ft
VA Boom - 2600 mm (8'6") Stick Length: Reach at Ground Level 30.83ft
One-Piece Boom - 2600 mm (8'6") Stick Length: Dump Height 20.42ft
VA Boom - 2600 mm (8'6") Stick Length: Dump Height 23.83ft
VA Boom - 2600 mm (8'6") Stick Length: Digging Depth 20ft
VA Boom - 2600 mm (8'6") Stick Length: Digging Height 34.25ft
VA Boom - 2400 mm (7'10") Stick Length: Reach at Ground Level 30.25ft
One-Piece Boom - 2400 mm (7'10") Stick Length: Reach at Ground Level 29.5ft
VA Boom - 2400 mm (7'10") Stick Length: Digging Depth 19.33ft
One-Piece Boom - 2400 mm (7'10") Stick Length: Digging Height 30ft
VA Boom - 2400 mm (7'10") Stick Length: Dump Height 23.42ft
One-Piece Boom - 2600 mm (8'6") Stick Length: Digging Depth 19.33ft

Weights

Operating Weight* 17 200 to 19 700 kg (37,919 to 43,431 lb)
VA Boom - Front and Rear Outriggers 41160lb
One-Piece Boom - Rear Dozer, Front Outriggers 39507lb
One-Piece Boom - Front and Rear Outriggers 40080lb
Note *Includes medium stick, 3400 kg (7,496 lb) counterweight, full fuel tank, operator, quick coupler (250 kg/551 lb), bucket (600 kg/1,323 lb), dual pneumatic tires. Weight varies depending on configuration.
Counterweights 3400/3900 kg (7,496/8,598 lb)
VA Boom - Rear Dozer, Front Outriggers 40587lb

Hydraulic System

System 55.5gal (US)
Maximum Pressure - Implement Circuit - Heavy Lift 5366psi
Maximum Pressure - Auxiliary Circuit - High Pressure 5076psi
Maximum Flow - Auxiliary Circuit - Medium Pressure 12.9gal/min
Maximum Pressure - Implement Circuit - Normal and Travel Circuit 5076psi
Maximum Flow - Auxiliary Circuit - High Pressure 67gal/min
Maximum Pressure - Auxiliary Circuit - Medium Pressure 2683psi
Maximum Flow - Implement/Travel Circuit 67gal/min
Swing Mechanism 5366psi
Maximum Flow - Swing Mechanism 22.2gal/min

Service Refill Capacities

Fuel Tank - Total Capacity 87.2gal (US)
Diesel Exhaust Fluid Tank 9.1gal (US)
