316F L Hydraulic Excavator

The Cat® 316F L is a perfect choice for customers who value versatility, reliability, durability, and maximum efficiency.


Net Power - ISO 9249 117HP
Engine Model C4.4
Engine Power - ISO 14396 122HP
Bore 4.13in
Stroke 5in
Displacement 269in³


Operating Weight 39029lb

Working Ranges & Forces

Maximum Digging Depth 20ft
Boom Reach 5.1 m (16'9")
Stick R2.6 m (8'6")
Bucket 0.76 m³ (1.0 yd³)
Maximum Reach at Ground Level 28.83ft
Maximum Cutting Height 29.25ft
Maximum Loading Height 20.58ft
Minimum Loading Height 7.5ft
Maximum Vertical Wall Digging Depth 16.25ft
Bucket Digging Force - ISO 24953lbf
Stick Digging Force - ISO 17984lbf

Hydraulic System

Main System - Maximum Flow 79 gal/min (300 l/min)
Maximum Pressure - Equipment 5076psi
Maximum Pressure - Swing 3626psi
Maximum Pressure - Travel 5076psi

Swing Mechanism

Swing Speed 8.9r/min
Maximum Swing Torque 36582ft·lbf

Service Refill Capacities

Fuel Tank Capacity 76.61gal (US)
Cooling System 6.9gal (US)
Engine Oil 3.57gal (US)
Swing Drive 2.11gal (US)
Final Drive - Each 2.11gal (US)
Hydraulic System - Including Tank 31.96gal (US)
Hydraulic Tank 28gal (US)
DEF Tank 5.4gal (US)


Boom Reach 5.1 m (16'9")
Stick R2.6 m (8'6")
Bucket 0.76 m³ (1.0 yd³)
Shipping Height - Top of Cab 10.17ft
Shipping Length 28.08ft
Tail Swing Radius 8.17ft
Counterweight Clearance 3.33ft
Ground Clearance 1.42ft
Track Length 13ft
Length to Center of Rollers 10ft
Track Gauge 6.5ft
Transport Width 8.83ft
