Cat® PM313 Cold Planers with integrated Cat Grade and Slope technology and the latest System K rotors are equipped to deliver performance, productivity and cutting precision. A comfortable operator environment puts intuitive controls at your fingertips, while long service intervals and easy maintenance access help simplify service. Although designed for a single operator, the PM313 includes features for supporting ground personnel. Many options are available to enhance machine versatility when optimum maneuverability or high production capabilities are required.
| Milling Width | 51.2in |
| Maximum Milling Depth | 13in |
| Rotor Speeds | 97 / 109 / 121 rpm |
| Number of Bits | 111 |
| Rated Power | 343hp |
| Engine | C9.3B |
| Maximum Travel Speed | 3.4mile/h |
| Maximum Milling Speed | 108ft/min |
| Operating Weight | 47522lb |
| Transport Weight | 46622lb |
| Operating Length - Conveyor Up | 36.45ft |
| Operating Width | 8.33ft |
| Height - Canopy | 12.3ft |
| Maximum Truck Clearance | 15.42ft |
| Minimum Right Cutting Radius | 6.3ft |
| Minimum Left Cutting Radius | 13.58ft |
| Conveyor Swing | ±60 degrees from center |
| Transport Length | 30.58ft |
| Transport Width | 8.33lb/in |
| Transport Height | 9.84ft |
| Fuel Tank | 137.9gal (US) |
| Engine Oil | 7.9gal (US) |
| Hydraulic Tank | 14.5gal (US) |
| Cooling System | 16.9gal (US) |
| Diesel Exhaust Fluid (DEF) Tank | 12.4gal (US) |
| Water Spray System Tank | 332.9gal (US) |
