Engine Model Cat® C7.1 ACERT™
Net Flywheel Power 239 hp
Net Power – SAE J1349/ISO 9249 239 hp
Gross Power – SAE J1995 242 hp
Bore 4.13 in
Stroke 5.31 in
Displacement 428 in3
Operating Weight 69902 lb
Minimum Operating Weight* 65169 lb
Maximum Operating Weight** 69902 lb
Note *6.15 m (20'2'') Reach Boom, R3.2CB2 (10'6") Stick, 600 mm (24") SG Shoes, 5.8 mt (6.3 t) Counterweight, 1.3 m3 (1.70 yd3) Bucket.
Note **10.2 m (33'6") SLR Boom, 7.85 m (25'9") Stick, 800 mm (31") TG Shoes, 6.75 mt (7.4 t) Counterweight, 0.53 m3 (0.69 yd3) Bucket.
Main System – Maximum Flow (Total) 130 gal/min
Maximum Pressure – Equipment Heavy Lift 5511 psi
Maximum Pressure – Equipment Normal 5076 psi
Maximum Pressure – Travel 5366 psi
Maximum Pressure – Swing 3974 psi
Pilot System – Maximum Flow 6.1 gal/min
Pilot System – Maximum Pressure 595 psi
Boom Cylinder – Bore 6 in
Boom Cylinder – Stroke 55 in
Stick Cylinder – Bore 6 in
Stick Cylinder – Stroke 65 in
CB2 Bucket Cylinder – Bore 5.9 in
CB2 Bucket Cylinder – Stroke 45.3 in
Maximum Travel Speed 3.2 mph
Maximum Drawbar Pull 55528 lbf
Swing Speed 9.6 rpm
Swing Torque 60628 lbf-ft
Service Refill Capacities
Fuel Tank Capacity 137.4 gal
Cooling System 7.9 gal
Engine Oil (with filter) 6.3 gal
Swing Drive (each) 2.3 gal
Final Drive (each) 1.6 gal
Hydraulic System (including tank) 81.9 gal
Hydraulic Tank 46.2 gal
DEF Tank 10.8 gal
Number of Shoes (each side) – Long Undercarriage 50
Number of Track Rollers (each side) – Long Undercarriage 9
Number of Carrier Rollers (each side) – Long Undercarriage 2
ISO 6396 – Operator Noise (Closed) 72 dB(A)
ISO 6395 – Spectator Noise 105 dB(A)
Brakes ISO 10265 2008
Cab/FOGS ISO 10262 1998
Note When properly installed and maintained, the cab offered by Caterpillar, when tested with doors and windows closed according to ANSI/SAE J1166 OCT98, meets OSHA and MSHA requirements for operator sound exposure limits in effect at time of manufacture.
Note Hearing protection may be needed when operating with an open operator station and cab (when not properly maintained or doors/windows open) for extended periods or in noisy environment.
Comfort and convenience to keep you productive
A Safe, Quiet Cab
The ROPS cab provides you with a safe working environment. It also contributes to your comfort because it’s attached to a reinforced frame with special viscous mounts that limit vibration and unnecessary sound. Add in special roof lining and sealing and you have a cab that’s as quiet inside as today’s top pickup trucks.Comfortable Seat Options
The seat range includes air suspension, heated, and air cooled options. All seats include a reclining back, upper and lower slide adjustments, and height and tilt angle adjustments to meet your needs for maximum comfort.A Cool and Warm Environment
The automatic climate control system features multiple air outlets with filtered ventilation. Air flows on the floor, behind the seat, and in front of you to make your work in either hot or cold weather much more pleasant and productive.Controls Just For You
The right and left joystick consoles can be adjusted to improve your comfort and productivity during the course of a day. Also, the right joystick features a button that will reduce engine speed when you are not working to help save fuel. Touch it once and speed reduces; touch it again and speed increases for normal operation.A Helpful Monitor
The LCD monitor is easy to see and navigate. Programmable in up to 44 languages to meet today’s diverse workforce, the monitor clearly displays critical information you need to operate efficiently and effectively. Plus it projects the image from the standard rearview camera to help you see what’s going on around you so you can stay safely focused on the job at hand.Ample Storage and Auxiliary Power
Storage spaces are located in the front, rear, and side consoles of the cab. A drink holder accommodates a large mug with handle, and a shelf behind the seat stores large lunch or toolboxes. Two 12-volt power supply sockets are conveniently located near the key storage areas for charging your electronic devices like an MP3 player, a cell phone, or a tablet.
Powerful and fuel efficient to meet your expectations
Proven Technology More Powerful, Reliable Engine Electronics
Every Tier 4 Final ACERT engine is equipped with a combination of proven electronic, fuel, air, and aftertreatment components. Applying these time-tested technologies lets us meet your high expectations for productivity, fuel efficiency, reliability, and service life. Following are the results you can expect:
- Improved fluid efficiency of up to 5% over Tier 4 Interim products, including Diesel Exhaust Fluid (DEF) consumption.
- High performance across a variety of applications.
- Enhanced reliability through commonality and simplicity of design.
- Maximized uptime and reduced cost with world-class Cat dealer support.
- Minimized impact on emission systems – with no operator interaction required.
- Durability with long service life.
- Better fuel economy with minimized maintenance costs.
- Same great power and response.
Cat Tier 4 Final engine electronics are more powerful and robust than ever. Features like an over-foam wiring harness enhance your experience and increase quality and reliability through the most demanding applications.Next Generation Fuel Systems
Injection timing precisely controls the fuel injection process, which provides more control of combustion for the cleanest, most efficient fuel burn. To maximize your value, Caterpillar engineers specified fuel systems based on the power and performance demands for each engine. The high-pressure common rail fuel system with full electronic injection improves precision and control, reducing soot and boosting the engine’s performance.Innovative Air Management
Cat Tier 4 Final engines feature innovative air management systems that optimize airflow and enhance power, efficiency, and reliability. A range of simple, reliable turbocharging solutions based on engine size and application allows us to match turbo performance to rated output for high productivity, excellent fuel efficiency, long life, and low operating costs for you.Cat NOx Reduction System
The Cat NOx Reduction System captures and cools a small quantity of exhaust gas and then routes it back into the combustion chamber to drive down temperatures and reduce NOx emissions. The result of more than a decade of Caterpillar engineering research into this technology is the most reliable system of its typeAftertreatment Technologies
Caterpillar designed Tier 4 Interim products with Tier 4 Final standards in mind. By planning ahead, we minimized design changes to deliver the reliability and performance you demand. The aftertreatment solution utilized for Tier 4 Final products is the next evolutionary step for Cat engines with ACERT Technology. To meet the additional 80% reduction in NOx emissions required by Tier 4 Final emission standards, Caterpillar engineers only needed to add one new system to the already proven aftertreatment solution in use, Selective Catalytic Reduction (SCR).Diesel Exhaust Fluid (DEF)
Cat engines equipped with an SCR system inject DEF into the exhaust to reduce NOx emissions. DEF is a precisely mixed solution of 32.5% high purity chemical grade urea and 67.5% de-ionized water. DEF used in Cat SCR systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1. ISO 22241-1 requirements are met by many brands of DEF, including those that carry the AdBlue or API certifications.An Emissions Solution That Works
The Cat C7.1 ACERT engine meets Tier 4 Final emission standards, and it does so without interrupting your job process. Simply turn the engine on and go to work. It will look for opportunities in your work cycle to regenerate itself, and it will give you plenty of power for the task at hand – all to help keep your owning and operating costs to an absolute minimum.Fuel Savers That Add Up
The 330F consumes less fuel than the previous series model, and the automatic engine speed control contributes by lowering rpm when the machine doesn’t need it for work. Automatic engine idle shutdown turns the engine off when it’s been idling for more than a specified amount of time that you can set through the monitor. Plus you have a choice of three power modes – high power, standard power, and eco mode. Simply change between modes through the console switch panel to meet the work needs in front of you. Collectively, all of these benefits add up to reduced fuel consumption, reduced exhaust and sound emissions, reduced repair and maintenance costs, and increased engine life for you.A Cool Design For Any Temperature
A side-by-side cooling system allows you to put the machine to work in extremely hot and cold conditions. The system is completely separated from the engine compartment to reduce noise and heat. Plus it features easy-to-clean cores and an efficient variable-speed fan.Biodiesel Not A Problem
The C7.1 ACERT engine can run on up to B20 biodiesel that meets ASTM 6751 standards – all to give you more potential fuel-saving flexibility.
Power to move your material with speed and precision
A Powerful, Efficient Design
When it comes to moving heavy material quickly and efficiently, you need hydraulic horsepower – the type of ground-breaking power the 330F can deliver. Major hydraulic components like pumps and valves are located close together so shorter tubes and lines can be used. This design leads to less friction loss, reduced pressure drops, and more power to the ground for the work you need to get done.Control Like No Other
Controllability is one of the main attributes of Cat excavators, and one of the key contributors to this is the main control valve. The valve opens slowly when your range of joystick lever movement is small and opens rapidly when movement is high. It puts flow where you need it when you need it, which leads to smoother operation, greater efficiency, and lower fuel consumption.Auxiliary Hydraulics For Added Versatility
Auxiliary hydraulics give you greater tool versatility so you can take on more work with just one machine, and there are several options from which you can choose. A quick coupler circuit, for example, will allow you to switch from one tool to another in a matter of minutes – all from the comfort and convenience of the cab.Boom and Stick Oil Re-Circulation For Added Efficiency
The 330F regenerates the flow of oil from the head end of the boom and stick cylinders to the rod end of the boom and stick cylinders during the work cycle to save energy and improve fuel efficiency. It’s optimized for any dial speed setting you select, which results in less pressure loss for higher controllability, more productivity, and lower operating costs for you.
Structures and Undercarriage
Made to work in your tough applications
The 330F is a well-built machine designed to give you a very long service life. The upper frame has mountings made specifically to support the heavy-duty cab; it is also reinforced around key areas that take on stress like the boom foot and skirt. Massive bolts are used to attach the track frames to the body, and additional bolts are used to increase the machine’s digging force, which leads to more productivity for you.Durable Undercarriage
The 330F undercarriage contributes significantly to its outstanding stability and durability. Track shoes, links, rollers, idlers, and final drives are all built with long-lasting, high-tensile-strength steel. Cat Grease Lubricated Track 2 (GLT2) track link protects moving parts by keeping water, debris, and dust out and grease sealed in, which delivers longer wear life and reduced noise when traveling. Optional guide guards help maintain track alignment to improve the machine’s overall performance – whether you’re traveling on a flat, heavy bed of rock or a steep, wet field of mud.Counterweight Options
Two counterweight options – 5.8 mt (6.3 t) and 6.75 mt (7.4 t) – are available. Both are built with thick steel plates and reinforced fabrications to make them less susceptible to damage, and both have curved surfaces that match the machine’s sleek, smooth appearance along with integrated housings to help protect the standard rearview camera.
Options to take on your far-reaching and up-close tasks
Booms and Sticks
The 330F is offered with a range of booms and sticks. Each is built with internal baffle plates for added durability, and each undergoes ultrasound inspection to ensure weld quality and reliability. Large box-section structures with thick, multi-plate fabrications, castings, and forgings are used in high-stress areas such as the boom nose, boom foot, boom cylinder, and stick foot to improve durability. The boom nose pin is a captured flag design for enhanced durability.Two Types Available
There are two basic boom options available to meet your work needs: STD and SLR.STD
This type of boom is best used for reach applications where conditions are optimal such as excavating basements, trenching for utility lines, and working in sewer applications.SLR = Super Long Reach
This configuration offers reaches to 60 feet. It is perfectly suited for forming slopes and cleaning settlement tanks and ponds.
Sticks are matched to the boom you choose. Longer sticks are better when you need to dig deep or load trucks. Shorter sticks provide greater breakout force and increase your productivity when using hydromechanical work tools.
Talk to your Cat dealer to pick the best front linkage for your line of work.
Monitor, manage, and enhance your job site operations
The smart use of technology and services will improve your job site efficiency. In fact, using data from technology equipped machines gives you more information and insight into your equipment and operations than ever before.
Cat Connect Technology for Excavators include:Cat LINK
Cat LINK Technology wirelessly connects you to your equipment, giving you valuable insight into how your machine or fleet is performing. The system tracks location, hours, fuel usage, productivity, idle time, and diagnostic codes through the online VisionLink® interface so you can make timely, fact-based decisions to maximize efficiency, improve productivity, and lower operating costs.Cat GRADE
Cat GRADE with Depth and Slope combines digital design data and in-cab guidance to help you work more productively and accurately with less rework. Real-time bucket tip positioning and cut and fill data on the standard cab monitor guide you to grade, saving money on fuel and materials.
Tools to make you productive and profitable
Get The Most Out Of One Machine
You can easily expand the performance of your machine by utilizing any of the variety of attachments offered by Cat Work Tools.Change Jobs Quickly
A quick coupler brings the ability to quickly change attachments and switch from job to job. The Cat Pin Grabber coupler is the secure way to decrease downtime and increase job site flexibility and overall productivity.Dig, Finish, Load and Compact
A wide range of buckets dig everything from top soil to harsh, abrasive material. For finishing and grading work, compact and shallow ditch cleaning buckets fit the need. A Cat compactor prepares the area for the next phase of construction.Mining, Demolition and Scrap
A hydraulic hammer equips your machine for breaking rock in quarries and preparing trenches on construction sites. Taking down bridge pillars and heavily reinforced concrete is no problem. Multi-processor, pulverizer, and shear attachments take your machine into structure demolition jobs and process the debris for reuse and recycle.Move and Handle
Add a thumb and you have the ability to move and handle brush, rocks, and debris. For constant material handling, a grapple is your solution. Choose from three different styles for picking, sorting, and loading trash, demolition debris, or recyclables.Set Up Your Machine For Profitability
Your Cat dealer can install hydraulic kits to properly operate all Cat Work Tool attachments – maximizing the machine’s uptime and your profits. All Cat Work Tool attachments are supported by the same Cat dealer network as your Cat machine.
Designed to make your maintenance quick and easy
You can reach most routine maintenance items like fluid taps and grease points from the safety and convenience of ground level. Not only do compartments feature wide service doors designed to help prevent debris entry, but they also securely latch in place to help make your service work simpler.A Cool Design
The high-ambient cooling system features a fuel-saving variable-speed fan and a side-by-side-mounted radiator and oil and air coolers for easy cleaning. Wider clearance between the two make blowing off debris easy for you, which can help improve your machine’s reliability and performance.A Fresh Idea
When you select ventilation inside the cab, outside air enters through the fresh air filter. The filter is conveniently located on the side of the cab to make it easy to reach and replace, and it is protected by a lockable door that can be opened with the engine key.Other Service Benefits
The fuel tank’s drain cock makes it easy and simple for you to remove water and sediment during routine maintenance. Plus an integrated fuel level indicator pops up to help you reduce the possibility of fuel tank overfilling.
Features to help protect you day in and day out
A Safe, Quiet Cab
The ROPS cab provides you with a safe working environment when properly seated and belted. It also contributes to your comfort because it’s attached to a reinforced frame with special viscous mounts that limit vibration and unnecessary sound. Add in special roof lining and sealing and you have a cab that’s as quiet inside as any of today’s top pickup trucks.Secure Contact Points
Multiple large steps get you into the cab as well as a leg up to the compartments. Extended hand and guard rails allow you to safely climb to the upper deck. Anti-skid plates reduce your slipping hazards in all types of weather conditions, and they can be removed for cleaning.Great Views
Ample glass gives you excellent visibility out front and to the side, and the standard rearview camera gives you a clear field of view behind the machine through the cab monitor. The available split-configuration windshield features an upper window with handles that make it easy to slide and store above you and a lower window that can be removed and stored on the inside wall of the cab. The large skylight also serves as an emergency exit and provides you with enhanced overhead visibility.Smart Lighting
Halogen lights provide plenty of illumination, and the cab and boom lights can be programmed to stay on for up to 90 seconds after the engine has been turned off to help you safely exit the machine. Optional High Intensity Discharge (HID) lights are available for enhanced night-time visibility.
Complete Customer Care
Support you can count on
Worldwide Parts Availability
Cat dealers utilize a worldwide parts network to maximize your machines’ uptime. Plus they can help you save money with Cat remanufactured components.Advice You Can Trust
What are the job requirements and machine attachments? What production is needed? Your Cat dealer can provide recommendations to help you make the right machine choices.Financial Options Just For You
Consider financing options and day-to-day operating costs. Look at dealer services that can be included in the machine’s cost to yield lower owning and operating costs over time.Support Agreements To Fit Your Needs
Cat dealers offer a variety of customer support agreements and work with you to develop a plan to meet your specific needs. These plans can cover the entire machine, including attachments, to help protect your investment.Operating Techniques To Boost Your Profits
Improving operating techniques can boost your profits. Your Cat dealer has videos, literature, and other ideas to help you increase productivity. Caterpillar also offers simulators and certified operator training to help maximize the return on your investment.What’s Best For You Today…And Tomorrow
Repair, rebuild, or replace? Your Cat dealer can help you evaluate the cost involved so you can make the best choice for your business.
Generations ahead in every way
- The C7.1 ACERT engine meets Tier 4 Final emission standards.
- The 330F performs the same amount of work while burning less fuel than the previous E Series model, which means more efficiency, less resources consumed, and fewer CO2 emissions.
- The 330F has the flexibility of running on either ultra-low-sulfur diesel (ULSD) fuel with 15 ppm of sulfur or less or biodiesel (up to B20) fuel blended with ULSD.
- A ground-level overfill indicator rises when the tank is full to help the operator avoid spilling.
- The QuickEvac™ option ensures fast, easy, and secure changing of engine and hydraulic oil.
- The 330F is built to be rebuilt with major structures and components capable of being remanufactured to reduce waste and replacement costs.
- An engine oil filter eliminates the need for painted metal cans and aluminum top plates. The cartridge-style spin-on housing enables the internal filter to be separated and replaced; the used internal element can be incinerated to help reduce waste.
- The 330F is an efficient, productive machine that’s designed to conserve our natural resources for generations ahead.
